銷售JOUCOMATIC捷高直動式先導閥

先導閥

常閉，直動式

螺紋體，1/8和M10

?6毫米快插接頭

產品特點

?雙向數控先導閥為除塵器服務

?常閉直動

?堅固的黃銅鍛造閥體結構

?專為面板安裝

?結構緊湊，重量輕建設

?組件符合所有相關的EC指令

主體黃銅

芯管不銹鋼

和plugnut不銹鋼

彈簧不銹鋼

底紋線圈銅

連接黑桃2個DIN-46244（A6.3x0.8）或

含鉛線圈460毫米

OPTIONS

? Epoxy moulded leaded coils or coils with spade plug connector (3 x DIN-46244)

? Pipe connection E = Rp (ISO 7/1) or compression type fitting inlet

? Pilot valves can be equipped with explosion proof solenoids for

hazardous locations according to

"ATEX" and national standards

INSTALLATION

? The solenoid valves are open frame constructions, designed for panel

mount or stand alone and can be installed in any

position without affecting operation

? Recommended maximum panel thickness is 6,0 mm and panel passage ? 20 mm

? Installation/maintenance instructions are included with each valve

? Replacement coils are available
