 2-way latching valve with 1/4 - 28 UNF, flat bottom ports and 24 vdc latching coil 330224S303 =

3, 2-way normally closed valves mounted on a manifold with 1/4 - 28 UNF, flat bottom ports and 24 vdc coil rated at 3.8 Watts Examples

Catalog Number Description and Options

3302                       xx                           S30                                2

Base Catalog Number (1st Part)

Voltage - 12  (DC) - 24  (DC)

Number of Solenoids - 2 - 3 - 4

? Select base catalog number ? Insert voltage into the 5th and 6th digits denoted by "xx" ? Add number of solenoids (330 series only)

Base Catalog Number (2nd Part)

 ? PTFE diaphragm shields the internal components of the solenoid from the media to handle the most aggressive fluids

? Compact size saves valuable space in equipment ? Low power consumptio

Valve Parts in Contact with Fluids Body PTFE Seat CTFE Diaphragm PTFE

 Standard Voltages 12, 24 VDC+ 10%, -5% Power Consumption 2.9 - 3.8 Watts (12 watts for latching version) Duty Cycle Rating Continuous

(Intermittent for latching version) Coil Insulation 356?F (180?C) Electrical Connection 26 gage lead wire

 Response Time                ~5 ms at rated voltage (2 watt coil) Internal Volume

 20 μL from port 1 to seat (not including port)

The Series 190 & 330 are 2-way, normally closed isolation valves constructed with TFE materials,

which makes them virtually impervious to chemical attack. The Series 190 is a single valve while

the Series 330 offers the same valve in a 2, 3, or 4 position manifold configuration

for use in chromatography, solvent selection, and process sampling.

Valve

Alternative Constructions Many alternative constructions are available and include a variety of voltages,

electrical connectors, and materials of construction.

ASCO Scientific can also custom design a valve for your specific application.

 Contact your local ASCO sales office for more information.

190212S30   =   2-way normally closed valve with 1/4 - 28 UNF,

flat bottom ports and 12 VDC coil rated at 2.9 Watts 190224L30   =

52 μL from port 2 to seat (not including port) Options                ? Magnetic Latching

? Single valve or 2, 3, and 4 position manifolds Vacuum Rating

Temperature Range: Ambient & Media: 32?F to 77?F (0?C to 25?C) continuous duty up to 104?F (40?C) intermittent duty

Approvals: Meets applicable CE directives
