cable, flexing: -20 ... 80 °C (-4 ... 176 °F)

cable, fixed: -40 ... 80 °C (-40 ... 176 °F)

Pollution degree 3

Mechanical specifications

Valve connectors for industrial applications have to meet many demands regarding quality and flexibility.

 The operational temperature range, degree of protection,

 and resistance against oils and greases are as relevant as the right combination of housing design,

 pole number, noise suppression, and cable type.

Degree of protection IP65/IP67

Connection Valve connector Form A

Sheath diameter ? 4.5 mm

 Bending radius > 50 mm

> 22.5 mm, fixed

 Color dark grey (RAL 7021)

 Our wide range of DIN EN 175301-803 valve connectors offers you a diverse combination of options that can fill nearly every application requirement.

The overmolded, integrated seal of the valve connectors improves usage and ensures the IP67 degree of protection.

Flame resistant cable

Valve connector, Form A, 2+PE, PUR cable

General specifications

Number of pins 2 + PE

Connection 1 Valve connector DIN

Construction type 1 right angle

Connection 2 cable end

Electrical specifications

Operating voltage 250 V AC/DC

Operating current max. 10 A

Volume resistance < 10 mΩ

 Cable types in both PUR and PVC gives users flexibility in choice for cable materials.

Model dependent protection circuits rated from 12 V to 230 V AC/DC

Ambient conditions

Ambient temperature Body: -25 ... 80 °C (-13 ... 176 °F)

 Cores (2 + 1) x 0.5 mm2 ; 20 AWG

 Conductor construction 28 x 0.15 mm ?

 Length 0.3 m

Drag chain suitability

 Drag chain cycles min. 15000000

 Motion velocity max. 5 m/s

 Traverse distance 0.9 m

 Acceleration max. 30 m/s2

and function indicators in the connector body limit dangerous voltage surges and ease maintenance in the field.

The high-quality materials used in the valve connector design excel in difficult environments and guarantee reliable operation.

 Due to the compact housing design, our valve connectors can be used in confined installation spaces.

The valve connectors are available in DIN and industrial versions

and can be supplied with open cable end or molded-on M12 connector.

Valve Connector Cordset VMA-2+P-0,3M-PUR

 Valve connector according EN 175301-803 A/ISO 4400 (previously DIN 43650)

Suitable for drag chains

freely selectable cable models due to bridged protective earth
