ASCO溫系列電磁閥，8210G078LT

電 話：021-39529830轉8009

手 機；18917074297

企業QQ；2880626083

郵箱；[email protected]

聯系人：鄭娜

DC Cryogenic Valves: -320°F to 120°F (-196°C to 49°C)

All Liquid CO2 Valves: -75°F to 120°F (-59°C to 49°C)

Refer to Engineering Section for details.

? All suffix “LT” valves are degreased, cleaned, tested

free of moisture, and black light tested for hydrocarbons

? Liquid CO2 valves are suitable for remote mounting or

Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.

(To order, add prefix “EF” to catalog number.)

See Optional Features Section for other available options

for direct mounting to the refrigerated component by

using four-hole bracket, provided

? “LT” suffix valves are built to control cryogenic fluids,

including liquid oxygen (-297°F/-181°C), liquid argon

(-303°F/-184°C), and liquid nitrogen (-320°F/-194°C)

AC Cryogenic Valves: -320°F to 150°F (-196°C to 66°C)

Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.

液氬（-303°F / -184°C）和液氮（-320°F / -194℃）

?所有后綴“LT”閥門都脫脂，清潔，測試無水分，黑色測試碳氫化合物

?液態CO2閥門適用于遠程安裝或通過使用四孔支架直接安裝到制冷部件

Body: Cryogenic Valves Brass

Body: LCO2 Valves Nickel-Plated Brass

Seals PTFE and/or Clad Copper/UR

?“LT”后綴閥用于控制溫流體，包括液氧（-297°F / -181°C），

Disc PTFE/UR (8264 only)

Core and Plugnut 430F Stainless Steel or 49 FM Alloy

Core Spring 302 Stainless Steel

Shading Coil Copper

Seats Stainless Steel (8264 Series

ASCO溫系列電磁閥，8210G078LT
